HH Roberts / Topwell TW-40-MV
15 Hp Bed Type CNC Mill
40" X axis travel


Available with
Anilam CNC logo  Heidenhain CNC logo  Fanuc CNC logo  Fagor CNC logo
FEB /09:
  We have developed a new variable speed drive for these machines
that can eliminate the need for a 600 V to 220 V transformer, reducing both the
purchase price and the installation wiring costs.

Topwell TW-40-MV Vertical bed type CNC milling machine
-travels   40" x 22" x 20"

-spindle Cat-V-40 or BT-40

-spindle drive 15 Hp or 22 Hp

-spindle speeds - standard 6,000 |


- 600 to 1000 IPM rapid traverse (according to control model and drive selection.) Shown here with the base mounted console support which is the most comfortable height for use.

Also available in overarm mounted configuration.

This model is available with toolchangers and fully enclosed.  See our MCO and MCV models.  The toolchangers can be field retrofitted

Click here for detailed specifications

Topwell TW-40-MV vertical CNC bed mill without table guards



TW-40-MV TW-40-MVW
Table 59" x 13" 59" x 18"
Travels 40" x 22" x 18" 40" x 22" x 23"
Spindle nose to table surface 22" 28"
Want handwheels ?:
we do not recommend handwheels but if you really think you need them, that arrangement is like that shown to the left.  The X axis handwheel is driven through a 90 degree bevel gear set.  All handwheels have spring declutching.
We suggest that the MPG (electronic handwheel ) is a better solution than the mechanical one.
