used Drill Presses and Radial Arm Drills

used Erlo TCA25 1" geared head power feed drill with coolant
in our shop now being prepared for sale. Picture coming soon
link to the new machine picture and specs
used Dar-Sin 750 Radial Drill  30" arm  SOLD
used Mecof radial drill with preselect head and tilt table  Coming in soon
used Havlik radial arm drill




used Havlik 4 foot radial drill
MT5  12 pre-select speeds 50 to 2240 rpm
6 power feeds, box table



used Dar-Sin DSR 750S Radial Drill

used Dar-Sin 750 radial drill with 30" arm
Drilling capacity 1 1/2"
Spindle motor 2 Hp
Spindle #4 MT
Spindle speed 6 from 88 to 1500
Spindle stroke 8"
3 power feeds
Head travel on arm approx 20"
Spindle C/L to column approx 10 to 301/2"
Elevation motor 1 Hp.

Box table approx 20 x 16 x 16 High.
Column Diameter 8 1/4"
550/3/60 electrics




Used Mecof 25PR radial drill
with pre-select spindle speeds / feeds
and tilting box table
The picture was taken as it came in the door.  Needs cleanup.

drilling capacity 30 mm
spindle # 4 MT
travel on arm  22"
quill diameter 74mm
12 preselect spindle speeds 46 to 2190 rpm
6 feeds
